Aluminium Honeycomb Core Blocks

Aluminum honeycomb is a lightweight core material offering excellent strength and good corrosion resistance for industrial applications at low cost. It is usually made from 3003 or 5052 aluminum alloy foil.

Send Inquiry

Aluminum Honeycomb core blocks



Huarui  aluminum honeycomb core  is adhesively-bonded of the aluminum foil, which produces one of the highest strength/weight and the highest surface-to –volume ratio of any structural material. Our aluminum honeycomb is made from 3003H18 and 5052H18 aluminum alloy foil.


Aluminum honeycomb core blocks are usually with 520mm width. Customers can cut to different thickness per their specification.


Honeycomb structure:




Aluminum honeycomb specifications:



1.Material type: A3003H18 / 5052H18

2.Cell side length (mm): 0.5, 0.6, 0.7, 0.8, 0.9, 1.0, 1.5, 1.83, 2, 2.5, 3, 4, 5, 6, 7.5, 10, 12, 15 mm    (cell size=cell side length/1.732);Cell Size (inch): 1/30”, 1/25”, 1/20”, 1/18”, 1/16”, 1/15”, 1/10”, 1/8”, 1/6”, 1/5”, ¼”, 1/3”, 3/8”, ½”, ¾”, 1”

3.Foil thickness: 0.025-0.08 mm, 0.1mm

4.Supplied in: Blocks, unexpanded slices or expanded sheets (Perforated or Non Perforated)

5.Height/Sheet Thickness: 1.5mm to 500mm

6.Max Sheet Sizes: 1700mm (L) x 8000mm (W)



SPECIFICATIONS

Super   micro-aperture
    honeycomb

Micro-aperture
    honeycomb

Reguar honeycomb

Cell size

available

1/30"
    0.87mm

1/25"
    1.04mm

1/15"
    1.73mm

1/10"
    2.6mm

1/8"
    3.17mm

1/6"
    3.47mm

1/5"
    5.2mm

1/4"
    6.35mm

1/3"
    8.47mm

3/8"
    9.53mm

1/2"
    12.7mm

3/4"
    19.05mm

4/5"
    20.32mm

1"
    25.9mm

Alu foil
    Alloy&thk(mm)

3003H18
    0.025
    0.03

3003H18
    0.025
    0.03

3003H18
    0.04

3003H18:0.04,0.05,0.06
    5052H18:0.04,0.05,0.06

3003H18:   0.04,0.05,0.06,0.07,
    0.08,0.1
    5052H18: 0.04,0.05,0.06

3003H18:     0.04,0.05,0.06,0.07,0.08,0.1
    5052H18:         0.04,0.05,0.06

Max expanded   size(mm)


300x300

300x300

1000x1000

1200x1200

1500x1500

2000x1600

2000x1700

8000x1700




Aluminum honeycomb features:



1.Lightweight & Strong

2.Excellent thermal and electric conductivity

3.Good sound insulation performance

4.Fire resistant

5.Fungus resistant

6.Moisture and corrosion resistant

7.High compression & shear strength



Aluminum honeycomb applications:


1.Aircraft panels and Lightweight Train Panels/Truck Panels

2.Marine Panels (Commercial vessels and naval vessel bulkheads)

3.And Railcar panels (Doors/Floors and Energy Absorbers/Bumpers)

4.Architectural/Building structural panels (Exterior architectural curtain wall panels)

5.Honeycomb table of Industrial equipment (Sacrificial Laser beds and Tables for laser cutting application)

6.Skis and snowboards

7.Flow straightness for air or fluids/ Air, water, fluid, and light directionalization

8.Heat exchanging/ heating, ventilation, air conditioning equipment and devices

9.RFI/EMC Shielded Vents (Electronic shielding enclosures)

10.Light collimation/ lighting/Illumination Separator

11.Honeycomb Energy Absorbers/ Energy absorption protective structures

12.Laminar Air Flow units/Air Ventilation and purification

13.Sandwich Panels/Honeycomb Composite Panels, Wall ceiling and partition panels

14.Clean Room Panels

15.Acoustic attenuation

16.Electronic Whiteboard

17.Catalytic Converter

18.Honeycomb Grid for Photography Application
