Common honeycomb door panels are made of aluminum honeycomb core and solid wood panels or other decorative panels, which are characterized by light weight and strong processability. This product is widely used to make indoor doors or doors of various cabinets.
Technical Parameter and Customization
Faced Sheets | aluminum, fiberglass, carbon fiber, zinc, HPL, galvanized sheet, stainless steel, etc. |
Standard Finishes | PVDF/PE coat, wood pattern, stone pattern, powder coating, anodized, mirror finish, printing, embossed, etc. |
Adhesive Film | water resistant adhesive film (-40℃ to 117℃ for general applications; -40℃ to 220℃ for high pressure process) |
Honeycomb Core | aluminum alloy (AA3003H18/5052H18) |
Cell Size | super micro-aperture honeycomb, micro-aperture honeycomb, regular honeycomb |
Aluminum Alloy Foil Thickness | 0.02, 0.03, 0.04, 0.05, 0.06, 0.07, 0.08, 0.09, 0.1 |
Standard | HB5443-90 |
Temperature Range Applied | -55℃~175℃ in long term |
Thickness Tolerance | ± 0.15mm |
Cell Size Tolerance | Within ± 10% |
Density Tolerance | Within ± 10% |
Certificate | RoHs |
Features and Advantages:
1. After the surface treatment, the aluminum honeycomb core can be formed by bonding various solid wood panels or decorative panels. Honeycomb door panels has good sound insulation and heat insulation performance. It has good sound insulation and heat insulation that the wooden interior doors cannot achieve.
2. At the same time, honeycomb door panels can avoid fire resistance defects, moisture resistance defects, cracking defects and deformation defects that wooden doors have. Secondly, honeycomb door panels are not affected by temperature and humidity differences.
3. According to customer's requirements, we can provide the required color. In addition, we can also provide various special coatings, such as fluorocarbon coating, etc. The special painting can ensure the uniformity and saturation of color, and the adhesion of the coating.
4. This is a product that can be recycled. It is used to replace the door panel materials such as wood, because honeycomb door panel is more environmentally friendly and will not release hazardous substance.
