Aluminum honeycomb core is bonded by multiple layers of aluminum foil, laminated, and then stretched to form a regular hexagonal honeycomb core.
Features
• Easy to clean
• Flame resistant
• Good sound resistance
• High stiffness and strength
• Scratcg resistance
Aluminum honeycomb core are supplied in many conditions,like expanded,unexpanded,slice,blocks,perforated,and customized. The honeycomb core are for certain applications.
| Aluminum honeycomb block | ||
 | Standard width | 500mm |
| Max length | 3500mm | |
| Max Thickness | 120mm | |
| Avaiable finish | Chromating | |
| Aluminum honeycomb slice | ||
 | Max Height | 120mm |
| Max Width | 3500mm | |
| Thickness | 1.5 -500mm | |
| Avaiable finish | Chromating | |
| Expanded honeycomb core | ||
Full sheet |
Die cut | |
| Customized honeycomb core product | ||
 |  | |
We offer a wide arrange of aluminum honeycomb cell size that can meet requirements from different industries.
| Foil thickness | 0.025mm to 0.13mm | ||||
| Cell size | 1/30" to 1" | ||||
| Standard alloy | 3003H18 & 5052H18 | ||||
| Density: | 11 to 182 kg/m³ | ||||
| Tolerance | Foil thickness | ±0.002mm | |||
| Density | ±10% | ||||
| Cellsize | ±10% | ||||
| Specification | Thickness | ±0.15mm | |||
| Expanded width | 0/+30mm | ||||
| Expanded length | 0/+50mm | ||||
| Temperature applied: | -55℃ to 175℃ | ||||
| Standard: | China Aviation Industry Standard HB5443-90 | ||||
| Certificate of Compliance | Rohs | ||||
| Smoke& toxicity tests | DIN 5510-2:2009 & DIN 54837:2007 | ||||
