Aluminum honeycomb core is made by aluminum foil bonding and hot pressing into a stack and pulled apart. Huarui produce aluminum honeycomb in some conditions,expanded,unexpanded,blocks,slices,perforated. Aluminum honeycomb core can be used in sandwich panels,filter,energy absorber,purfication,laser table and so on.
Features
• High thermal conductivity
• Fungi resistant
• Environment protection
• Recycled
| Expanded honeycomb core | ||
Full sheet |
Die cut | |
Huarui honeycomb is the largest scale manufacturer of aluminum honeycomb in southern China with 10 production lines that allow us to produce 100 MT of aluminum honeycomb per month.
We offer a wide range of aluminum honeycomb cellsize that can meet the request of different industries.
Aluminum honeycomb core factory standard
| Foil thickness | 0.025mm to 0.13mm | ||||
| Cell size | 1/30" to 1" | ||||
| Standard alloy | 3003H18 & 5052H18 | ||||
| Density: | 11 to 182 kg/m³ | ||||
| Tolerance | Foil thickness | ±0.002mm | |||
| Density | ±10% | ||||
| Cellsize | ±10% | ||||
| Specification | Thickness | ±0.15mm | |||
| Expanded width | 0/+30mm | ||||
| Expanded length | 0/+50mm | ||||
| Temperature applied: | -55℃ to 175℃ | ||||
| Standard: | China Aviation Industry Standard HB5443-90 | ||||
| Certificate of Compliance | Rohs | ||||
| Smoke& toxicity tests | DIN 5510-2:2009 & DIN 54837:2007 | ||||
